Access Control IP65 Waterproof Function Keypad Stainless Steel Numeric

Access Control IP65 Waterproof Function Keypad Stainless Steel Numeric

IP65 Access Control Keypad

Numeric Access Control Keypad

IK07 Vandal Resistant Function Keypad

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Keypad Material:
304 Stainless Steel
Front Plate Dimension:
92 X 76.5 Mm
Protection Level:
Vandal Resistant:
Interface Port:
Access Control, Vending Kiosk
Payment & Shipping Terms
Minimum Order Quantity
1 unit
It depends on quantity
Packaging Details
High quality carton with customized foam inside
Delivery Time
Within 3 working days for sample(US layout)
Payment Terms
T/T.west union, L/C, MoneyGram
Supply Ability
3000pcs per month
Product Description

IP65 Access Control Waterproof Function Keypad Stainless Steel Numeric Keypad


IP65 IK07 Stainless Steel Access Control Function Keypad Numeric Metal Keypad with 3x4 12 Keys USB Interface


Faceplate Dimensions(W×H): 92×76.5mm


KMY3502J-1 model keypad is a stainless steel keypad with both numeric and function keys.The layout with function keys could be customized into any language. It is plug and play metal keypad, rear mounting installation .



Ø   Check-in Kiosk

Ø   Boarding Kiosk

Ø   Info-Kiosk

Ø   Internet Kiosk

Ø   Medical Kiosk

Ø   Industrial control platform

Ø   Gaming machine

Ø   Access control platform



Ø  High quality stainless steel keypad with trackball

Ø  Customizable layout, dimension and installation design

Ø  16 keys: 10 numeric keys and 6 function keys

Ø  Dustproof, waterproof, shake-proof, pickproof, drill-proof, bombproof

Ø  Ports for optional eight external function keys, beeper and guide light

Ø  IP Protection Class IEC/DIN/EN/ 60529:IP65

Ø  IK Protection Class DIN EN 50102:IK07


Mechanical Performance
Panel Features Imported stamping stainless steel material, oil-free, does not absorb sweat
Keys Stainless steel material
Key lifetime > 2,000,000 cycles per key
Force on keys 2.5~3.5N
Key Travel >0.45mm
Wide voltage input 5V DC +/- 10%



Environment Requirements

Ø  Only the front panels shall be exposed to outdoor climate. The panels are dustproof, waterproof, shake-proof, pickproof, drill-proof and bombproof.

Ø  Operating temperature range: 0℃‑ 60℃

Ø  Storage temperature range: –25℃ - 80℃

Ø  Relative humidity: 30%~90%

Ø  Atmospheric pressure: 60~106 KPa


Access Control IP65 Waterproof Function Keypad Stainless Steel Numeric 0

Access Control IP65 Waterproof Function Keypad Stainless Steel Numeric 1
