Panel Mounted IP65 Kiosk Metal Keyboard With Trackball Pointing Device

Panel Mounted IP65 Kiosk Metal Keyboard With Trackball Pointing Device

metal computer keyboard

metal keyboard with trackball

Place of Origin:

China

Brand Name:

KMY

Certification:

CE,ROHS,FCC

Model Number:

KMY299B-2

Contact Us

Request A Quote
Product Details
Payment & Shipping Terms
Minimum Order Quantity
50
Price
It depends on quantity
Packaging Details
High quality carton with customized foam inside
Delivery Time
Within 3 working days for sample(US layout)
Payment Terms
T/T.west union
Supply Ability
3000pcs per month
Product Description

Panel Mounted IP65 Kiosk Metal Keyboard With Trackball Pointing Device





Faceplate Dimensions(W×H):431×126mm (see drawing as below)







KMY299B-2 is made of high quality 304 stainless steel.Different language layout is available without additional charge.PS2 and USB interface can be optional.It is widely used on the kiosks and industrial equipments which need to be input varied informations.





Features:



Ø  65 keys stainless steel panel mount keyboard

Ø  Support OS: Windows 95/98/NT/ME/2000/2003/XP/Vista, Linux and Unix

Ø  Waterproof and dustproof

Ø  Very rugged vandal proof design

Ø  Can be cleaned with soapy water, disinfectant or other cleaning agents

Ø  Carbon-on-Gold key switch technology PCB

Ø  PS/2 or USB interface available

Ø  Customized language layout available

Ø  Front Panel mounting solution





Material:



Ø  Front Panel: High quality stainless steel

Ø  Keys: High quality stainless steel

Ø  Back panel: Aluminum

Ø  Trackball: High quality stainless steel





Dimensions:



Ø  Front Panel: 431 ×126mm





Mechanical Performance:



Ø  Operating Temperature:-10°to+50°

Ø  Storage Temperature: -30°to +80°

Ø  Relative humidity: 30%~95%

Ø  Atmospheric pressure: 50 to 110kPa

Ø  Lifespan: >1 million operations per key

Ø  Key trip: 2mm

Ø  Key pressure: 120g

Ø  Weight: 2.3kg





Electrical Performance:



Ø  Voltage: 5.0VDC±5%

Ø  Electric current: 10mA

Ø  EMC Emission: EN55022(B)





Reliability:



Ø  MTBF: >20,000 hours

Ø  MTTR: < 30 minutes

Ø  CE, FCC, RoHS compliant

Ø  Waterproof and dustproof Class: IP65

Ø  Vandal resistant: IK07
