3*5 Keys Stainless Steel Keyboard 0.45mm Key Travel Cash Machine Keypad

3*5 Keys Stainless Steel Keyboard 0.45mm Key Travel Cash Machine Keypad

3*5 Keys Stainless Steel Keyboard

0.45mm Cash Machine Keypad

0.45mm Stainless Steel Keyboard

Place of Origin:

China

Brand Name:

KMY

Certification:

CE,ROHS,FCC

Model Number:

KMY3502C-15

Contact Us

Request A Quote
Product Details
Material:
Stainless Steel
Interface:
USB Or PS/2
Number Of Keys:
3*5 Key Buttons
Layout:
Customizable
Application:
Access Control, Vending Kiosk
Payment & Shipping Terms
Minimum Order Quantity
50 units
Price
It depends on quantity
Packaging Details
High quality carton with customized foam inside
Delivery Time
Within 3 working days for sample(US layout)
Payment Terms
T/T.west union, L/C,
Supply Ability
3000pcs per month
Product Description



3*5 Keys Stainless Steel Numeric Kiosk Metal Keyboard With Customized Layout





Faceplate Dimensions(W×H):74×150mm (see drawing as below)





KMY3502C-15 is a stainless steel keypad with both numeric and function keys .

The layout could be any language and function keys could be customized .

rear mounting  installation .





Application



Ø   Check-in Kiosk

Ø   Boarding Kiosk

Ø   Info-Kiosk

Ø   Internet Kiosk

Ø   Medical Kiosk

Ø   Industrial control platform

Ø   Gaming machine

Ø   Access control platform





Physical Features



Ø  Keypad made of high quality stainless steel

Ø  Customizable layout, dimension and installation design

Ø  Dustproof, waterproof, shake-proof, pickproof, drill-proof, bombproof

Ø  Ports for optional eight external function keys, beeper and guide light

Ø  IP Protection Class IEC/DIN/EN/ 60529:IP65

Ø  IK Protection Class DIN EN 50102:IK07

Ø  GW: 0.5KG





Reliability and Performance Data



Ø  Key lifetime > 2,000,000 cycles per key

Ø  Force on keys: 3~5 N

Ø  Key travel: 0.45mm

Ø  Wide voltage input: 5V DC +/- 20%

Ø  In running state, 5 V +/- 20% is needed; the electrical current is up to 100 mA and the actual power consumption is below 1.5W.

Ø  Running lifetime > 5 years; Battery lifetime > 5 years (without external power supply)





Environment Requirements



Ø  Only the front panels shall be exposed to outdoor climate. The panels are dustproof, waterproof, shake-proof, pickproof, drill-proof and bombproof.

Ø  Operating temperature range: 0℃‑ 45℃

Ø  Storage temperature range: –25℃ - 65℃

Ø  Maximum humidity in operating environment: 80%



3*5 Keys Stainless Steel Keyboard 0.45mm Key Travel Cash Machine Keypad 0
