Anti Vandal 3.5N Metal Numeric Keypad With Industrial Trackball Mouse 5VDC

Anti Vandal 3.5N Metal Numeric Keypad With Industrial Trackball Mouse 5VDC

Anti Vandal Metal Numeric Keypad

3.5N Metal Numeric Keypad

5VDC Industrial Trackball Mouse

Place of Origin:

China

Brand Name:

KMY

Certification:

CE,ROHS,FCC

Model Number:

KMY3505A

Contact Us

Request A Quote
Product Details
Payment & Shipping Terms
Minimum Order Quantity
50
Price
It depends on quantity
Packaging Details
High quality carton with customized foam inside
Delivery Time
Within 3 working days for sample(US layout)
Payment Terms
T/T.west union
Supply Ability
3000pcs per month
Product Description



Anti-vandal IP65 Numeric Kiosk Metal Keyboard With Poingting Device Metal Trackball And Functional Keys





Faceplate Dimensions(W×H):100×196



Anti-vandal IP65 Numeric Kiosk Metal Keyboard With Poingting Device Metal Trackball And Functional Keys





KMY3505As a stainless steel keypad with both numeric and function keys .

The layout could be any language and function keys could be customized .

rear mounting installation .





Application



Ø   Check-in Kiosk

Ø   Boarding Kiosk

Ø   Info-Kiosk

Ø   Internet Kiosk

Ø   Medical Kiosk

Ø   Industrial control platform

Ø   Gaming machine

Ø   Access control platform





Features



Ø  High quality stainless steel keypad with trackball

Ø  Customizable layout, dimension and installation design

Ø  16 keys: 10 numeric keys and 6 function keys

Ø  Dustproof, waterproof, shake-proof, pickproof, drill-proof, bombproof

Ø  Ports for optional eight external function keys, beeper and guide light

Ø  IP Protection Class IEC/DIN/EN/ 60529:IP65

Ø  IK Protection Class DIN EN 50102:IK07





Reliability and Performance Data



Ø  Key lifetime > 2,000,000 cycles per key

Ø  Force on keys: 2.5~3.5 N

Ø  Key travel: >0.45mm

Ø  Wide voltage input: 5V DC +/- 10%

Ø  Running lifetime > 5 years; Battery lifetime > 5 years (without external power supply)





Environment Requirements



Ø  Only the front panels shall be exposed to outdoor climate. The panels are dustproof, waterproof, shake-proof, pickproof, drill-proof and bombproof.

Ø  Operating temperature range: 0℃‑ 60℃

Ø  Storage temperature range: –25℃ - 80℃

Ø  Relative humidity: 30%~90%

Ø  Atmospheric pressure: 60~106 KPa



Anti Vandal 3.5N Metal Numeric Keypad With Industrial Trackball Mouse 5VDC 0
