Dustproof Kiosk Metal Keyboard

Dustproof Kiosk Metal Keyboard

Panel Mounting Kiosk Metal Keyboard

Dustproof Kiosk Metal Keyboard

74×74mm Kiosk Metal Keyboard

Place of Origin:

China

Brand Name:

KMY

Certification:

CE,ROHS,FCC

Model Number:

KMY3502H

Contact Us

Request A Quote
Product Details
Payment & Shipping Terms
Minimum Order Quantity
50
Price
It depends on quantity
Packaging Details
High quality carton with customized foam inside
Delivery Time
Within 3 working days for sample(US layout)
Payment Terms
T/T.west union
Supply Ability
3000pcs per month
Product Description



Panel Mounting Stainless Steel Kiosks Metal Keyboard For Access Control System







Faceplate Dimensions(W×H):74×74mm



KMY3502H is a stainless steel keypad with both numeric and function keys .

The layout could be any language and function keys could be customized .

rear mounting installation .







Application

Ø   Check-in Kiosk

Ø   Boarding Kiosk

Ø   Info-Kiosk

Ø   Internet Kiosk

Ø   Medical Kiosk

Ø   Industrial control platform

Ø   Gaming machine

Ø   Access control platform







Features

Ø  Mini Keypad made of high quality stainless steel

Ø  Customizable layout, dimension and installation design

Ø  16 keys: 10 numeric keys and 6 function keys

Ø  Dustproof, waterproof, shake-proof, pickproof, drill-proof, bombproof

Ø  Ports for optional eight external function keys, beeper and guide light

Ø  IP Protection Class IEC/DIN/EN/ 60529:IP65

Ø  IK Protection Class DIN EN 50102:IK07







Reliability and Performance Data

Ø  Key lifetime > 2,000,000 cycles per key

Ø  Force on keys: 2.5~3.5 N

Ø  Key travel: >0.45mm

Ø  Wide voltage input: 5V DC +/- 10%







Environment Requirements

Ø  Only the front panels shall be exposed to outdoor climate. The panels are dustproof, waterproof, shake-proof, pickproof, drill-proof and bombproof.

Ø  Operating temperature range: 0℃‑ 60℃

Ø  Storage temperature range: –25℃ - 80℃

Ø  Relative humidity: 30%~90%

Ø  Atmospheric pressure: 60~106 KPa
