478*135mm Full Metal Mechanical Keyboard 2.4KGS stainless steel keyboard

478*135mm Full Metal Mechanical Keyboard 2.4KGS stainless steel keyboard

478*135mm Full Metal Mechanical Keyboard

2.4KGS Stainless Steel Keyboard

478*135mm Stainless Steel Keyboard

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Payment & Shipping Terms
Minimum Order Quantity
It depends on quantity
Packaging Details
High quality carton with customized foam inside
Delivery Time
Within 3 working days for sample(US layout)
Payment Terms
T/T.west union
Supply Ability
3000pcs per month
Product Description



Information IP65 Kiosk Metal Keyboard With Touchpad And Numeric Keypad



Faceplate dimensions: 478*135 mm






This is a metal keyboard with touchpad made of high quality stainless steel ,you could use it on Check-in Kiosk, Boarding Kiosk, Info-Kiosk, Medical Kiosk, Industrial Control Platform, Gaming Machine and etc.




KMY299H-T Packing list includes 1Xkmy299H-T keyboard, 1X cable (USB/PS2 port connect to PC )





Ø  Front Panel: 478 x 135mm

Ø  Overall: 502 x 159mm

Ø  Touchpad: 60 x 45mm




Interface: USB or PS/2




Outstanding Features:

Ø  104 keys stainless steel panel mounting keyboard with touchpad and numeric keypad

Ø  Support OS: Windows 95/98/NT/ME/2000/2003/XP/Vista, Linux and Unix

Ø  Customized layout available

Ø  Lettering by etching and inking, or laser technology

Ø  Carbon-on-Gold key switch technology (silicon gel)

Ø  Waterproof and dustproof

Ø  Very rugged vandal proof design

Ø  Can be cleaned with soapy water, disinfectant or other cleaning agents





Ø  Front Panel: High quality 304# stainless steel

Ø  Keys: High quality 304# stainless steel

Ø  Back panel: Aluminum alloy




Mechanical Data:

Ø  Key trip: 1.5mm

Ø  Key pressure: 0.8~1.6 N

Ø  Lifespan: >2 million operations per key

Ø  Gross Weight: 2.4 KGS




Electrical Data:

Ø  Input Voltage: 5.0VDC±5%

Ø  Electric Current: 10mA

Ø  EMC Emission: EN55022

Ø  ESD Standard: Air Discharge 8KV; Contact Discharge 6KV




Environmental Adaptability:

Ø  Operating Temperature: 0°~+60°

Ø  Storage Temperature: -25°~+80°

Ø  Relative humidity: 30%~90%

Ø  Atmospheric pressure: 60~106 KPa





Ø  MTBF: >20,000 hours

Ø  MTTR: < 30 minutes

Ø  CE, FCC, RoHS, ESD compliant

Ø  Waterproof and Dustproof class: IP65 (front panel)

Ø  Vandal resistant class: IK07


478*135mm Full Metal Mechanical Keyboard 2.4KGS stainless steel keyboard 0
