Anti Vandal Kiosk Mechanical Metal Keyboard Dustproof Front Mounting
Front Mounting Anti-vandal Stainless Steel Kiosk Metal Keyboard with Trackball
Faceplate Dimensions(W×H):400×124mm (see drawing as below)
KMY299B-1 is made of high quality 304 stainless steel.Different language layout is available without additional charge.PS2 and USB interface can be optional.It is widely used on the kiosks and industrial equipments which need to be input varied informations.
Application
Ø Check-in Kiosk
Ø Boarding Kiosk
Ø Info-Kiosk
Ø Internet Kiosk
Ø Medical Kiosk
Ø Industrial control platform
Ø Gaming machine
Ø Access control platform
Material:
Ø Front Panel: High quality stainless steel
Ø Keys: High quality stainless steel
Ø Back panel: Aluminum
Ø Trackball: High quality stainless steel
Dimensions:
Ø Front Panel: 400 ×124mm
Mechanical Performance:
Ø Operating Temperature:-10°to+50°
Ø Storage Temperature: -30°to +80°
Ø Relative humidity: 30%～95%
Ø Atmospheric pressure: 50 to 110kPa
Ø Lifespan: >1 million operations per key
Ø Key trip: 2mm
Ø Key pressure: 120g
Ø Weight: 2.1kg
Electrical Performance:
Ø Voltage: 5.0VDC±5%
Ø Electric current: 10mA
Ø EMC Emission: EN55022(B)
Reliability:
Ø MTBF: >20,000 hours
Ø MTTR: < 30 minutes
Ø CE, FCC, RoHS compliant
Ø Waterproof and dustproof Class: IP65
Ø Vandal resistant: IK07
