16 Keys Metal Keypad Interactive Kiosk Metal Keyboard With Customizable Layout

16 Keys Metal Keypad Interactive Kiosk Metal Keyboard With Customizable Layout

metal computer keyboard

stainless steel keyboard

16 Keys Kiosk Metal Keyboard

Place of Origin:

China

Brand Name:

KMY

Certification:

CE,ROHS,FCC

Model Number:

KMY3502F

Contact Us

Request A Quote
Product Details
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
It depends on quantity
Packaging Details
High quality carton with customized foam inside
Delivery Time
Within 3 working days for sample(US layout)
Payment Terms
T/T.west union
Supply Ability
3000pcs per month
Product Description



16 Keys Metal Keypad Interactive Kiosk Metal Keyboard With Customizable Layout







Faceplate Dimensions(W×H):87.5×91.5mm







KMY3502F is a stainless steel keypad with both numeric and function keys .

The layout could be any language and function keys could be customized .

rear mounting installation .







Application

Ø   Check-in Kiosk

Ø   Boarding Kiosk

Ø   Info-Kiosk

Ø   Internet Kiosk

Ø   Medical Kiosk

Ø   Industrial control platform

Ø   Gaming machine

Ø   Access control platform







Features:

Ø  Keypad made of high quality stainless steel

Ø  Customizable layout, dimension and installation design

Ø  16 keys: 10 numeric keys and 6 function keys

Ø  Dustproof, waterproof, shake-proof, pickproof, drill-proof, bombproof

Ø  Ports for optional eight external function keys, beeper and guide light







Reliability and Performance Data

Ø  Key lifetime > 2,000,000 cycles per key

Ø  Force on keys: 2.5~3.5 N

Ø  Key travel: >0.45mm

Ø  Wide voltage input: 5V DC +/- 10%

Ø  Running lifetime > 5 years







Environment Requirements

Ø  Only the front panels shall be exposed to outdoor climate. The panels are dustproof, waterproof, shake-proof, pickproof, drill-proof and bombproof.

Ø  Operating temperature range: 0℃‑ 60℃

Ø  Storage temperature range: –25℃ - 80℃

Ø  Relative humidity: 30%~90%

Ø  Atmospheric pressure: 60~106 KPa



16 Keys Metal Keypad Interactive Kiosk Metal Keyboard With Customizable Layout 0
