Place of Origin:
China
Brand Name:
KMY
Certification:
CE,ROHS,FCC
Model Number:
KMY299J-4
Contact Us
Rugged Vandal Proof Numeric Keyboard Stainless Steel With Trackball
Stainless Internet Kiosk Metal Keyboard With Trackball And Numeric Keypad
Faceplate Dimensions(W×H):302×100mm (see drawing as below)
KMY299J-4 is made of high quality 304 stainless steel.Different language layout is available without additional charge.PS2 and USB interface can be optional.It is widely used on the kiosks and industrial equipments which need to be input varied informations.
Features:
Ø 82 keys stainless steel top panel mounting keyboard with trackball and numeric keypad
Ø Support OS: Windows 95/98/NT/ME/2000/2003/XP/Vista, Linux and Unix
Ø Excellent tactile sense by special “U” shaped keys
Ø Customized layout available
Ø Lettering by etching and inking, or laser technology
Ø Carbon-on-Gold key switch technology (silicon gel)
Ø Waterproof and dustproof
Ø Very rugged vandal proof design
Ø Can be cleaned with soapy water, disinfectant or other cleaning agents
Material:
Ø Front Panel: High quality 304# stainless steel
Ø Keys: High quality 304# stainless steel
Ø Trackball: High quality 304# stainless steel
Ø Back panel: Aluminum alloy
Mechanical Data:
Ø Key trip: 1.5mm
Ø Key pressure: 0.8～1.6 N
Ø Lifespan: >2 million operations per key
Ø Gross Weight: 2.0 KGS
Electrical Data:
Ø Input Voltage: 5.0VDC±5%
Ø Electric Current: 10mA
Ø EMC Emission: EN55022
Ø ESD Standard: Air Discharge 8KV; Contact Discharge 6KV
Environmental Adaptability:
Ø Operating Temperature: 0°～+60°
Ø Storage Temperature: -25°～+80°
Ø Relative humidity: 30%～90%
Ø Atmospheric pressure: 60～106 KPa
Reliability:
Ø MTBF: >20,000 hours
Ø MTTR: < 30 minutes
Ø CE, FCC, RoHS, ESD compliant
Ø Waterproof and Dustproof class: IP65 (front panel)
Ø Vandal resistant class: IK07
